• Direct display of Humidity & Temperature. No need of Look-Up table.
• Digital Offset setting for Temperature and Humidity
• No need for any water container & wet wick as in a Dry/Wet type Humidity Indicator. Maintenance free.
• Easy to calibrate & compare with Mercury in Glass thermometer systems.
• Large 0.8” RED 7 Segment displays gives long distance visibility.
• Rugged ABS cabinet with attractive look.
• Convenient wall mounting on bracket at rear.
Your custom text or HTML.
| Display | 3 Digits 7 Segment LEDs 0.8” character height (For Humidity) |
|---|---|
| Resolution | 0.1% For Relative Humidity & |
| Range | 5 to 95% Humidity and 0 to 99.9˚C temperature |
| Offset Setting | -9.9 ˚C to +9.9 ˚C for Temperature |
| Accuracy | ± 3% ± 1 Least Significant Digit for Humidity. |
| Sensors | Capacitive for Humidity |
| Power | 230V AC ± 15% |
| Relay | NO-P-NC (Potential Free) relay contacts with rating of 220V/5A |
| Cabinet | Strong ABS plastic cabinet. |
| Mounting | Wall mounted using key-hole type Bracket at rear. |
| Size | 151mm x 109mm x 55mm |
| Weight | 700 gms |
