Name: Panel Mounted Tachometer (Non Contact) using a Pro
SKU: CT200
Availability: InStock

Panel Mounted Tachometer (Non Contact) using a Pro

Original price was: 78.00$.Current price is: 68.00$.

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Fusce laoreet, ligula condimentum tincidunt, arcu orci laoreet massa, nec sagittis elit urna in diam. Sed consectetur dolor non nulla porttitorLorem ipsum dolor sit amet, consectetur adipiscing elit.

SKU: CT200

Description

Wide Measurement range from 15 RPM to 75,000 RPM.
Available in both 48×96 and 96x96mm front
High brightness LED display with leading zero blanking gives the exact RPM.
This tachometer uses an advanced Micro Computer LSI Circuit with Quartz Crystal time base to give high accuracy and fast measurement.
The use of a durable, strong metallic power coated housing assures maintenance free performance for many years.

Additional information

Your custom text or HTML.

Display	4 Digit Red LED 0.56″ character Height
Range	20 to 9999 RPM (resolution 1RPM) and 10,000-50,000 RPM (resolution 10 RPM)
Sensor	Non-contact proximity sensor to take 1 pulse/rev from rotor
Sensor Supply	10V to drive proximity sensor
Accuracy	+/- 1 RPM +/- 1 digit in the range 20 to 9999 RPM
Size	96x96mm or 48x96mm
Supply	220V AC +/- 15%
Mounting	Panel Mounting

Additional Information

Display:

4 Digit Red LED 0.56″ character Height

Range:

20 to 9999 RPM (resolution 1RPM) and 10,000-50,000 RPM (resolution 10 RPM)

Sensor:

Non-contact proximity sensor to take 1 pulse/rev from rotor

Sensor Supply:

10V to drive proximity sensor

Accuracy:

+/- 1 RPM +/- 1 digit in the range 20 to 9999 RPM

Size:

96x96mm or 48x96mm

Supply:

220V AC +/- 15%

Mounting:

Panel Mounting
