Sale!
Conductivity Transmitter

Blind Conductivity Transmitter (No Display) (Input: Factory set, Output:4-20mA), Non-Isolated

Please install and activate YITH WooCommerce Wishlist to add product wishlist
Category : Conductivity
SKU: 1004-COND
Download Catalogue

Description

  • Precision indication of conductivity in 4-20mA output
  • Automatic Temperature Compensation @2%/˚C using PT-100
  • Range can be provided from 19.99 µs to 199.9mS (Factory Set)
  • Aesthetically designed weather-proof cabinet

Additional information

Your custom text or HTML.

Range

19.99ms 199.9ms
(Factory Set)

1999 µs 19.99ms
199.9µs 1999 µs
19.99µs 199.9µs
(0.1Cell) (1.0 Cell)
Accuracy

± 0.5% of F.S. ± 1 LSD
Sensor

‘Contact type’ with Cell constant 0.1 or 1.0.
Temperature

Uses PT-100, precision temperature Comp.
sensor (external). The compensation is
internally set at 2%/˚C
Supply

220V AC ± 15% @ 50Hz/60Hz
Size

198mm x 89mm x 60mm (LxWxH) – with flange

Additional Information

Range:
19.99ms 199.9ms
(Factory Set):
1999 µs 19.99ms 199.9µs 1999 µs 19.99µs 199.9µs (0.1Cell) (1.0 Cell)
Accuracy:
± 0.5% of F.S. ± 1 LSD
Sensor:
‘Contact type’ with Cell constant 0.1 or 1.0.
Temperature:
Uses PT-100, precision temperature Comp. sensor (external). The compensation is internally set at 2%/˚C
Supply:
220V AC ± 15% @ 50Hz/60Hz
Size:
198mm x 89mm x 60mm (LxWxH) – with flange
