Name: 16 Channel Data Logger (Data Acquisition Systems) with Direct USB Pen Drive
SKU: 410
Availability: InStock

16 Channel Data Logger (Data Acquisition Systems) with Direct USB Pen Drive

Original price was: 78.00$.Current price is: 68.00$.

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Fusce laoreet, ligula condimentum tincidunt, arcu orci laoreet massa, nec sagittis elit urna in diam. Sed consectetur dolor non nulla porttitorLorem ipsum dolor sit amet, consectetur adipiscing elit.

Description

Data saved directly on USB Pen drive in an MS Excel compatible file
Microprocessor based linearised for J/K/R Thermocouples and PT100 temperature sensors.
4 line alphanumeric LCD display with backlight for user friendly displays
Auto cold junction compensation for thermocouples and 3 wire input for PT100
Number of usable channels selectable from 1-16.
Auto/Manual mode of scanning selectable
Rate of logging settable by user in Mins:Secs
Digital offset user settable for individual channels
Internal Real Time Clock with battery backup for saving values along with Date and Time
No need of any complicated or additional software for managing data
Saving data on Pen drive allows a very large amount of storage space at very low cost.

Additional information

Your custom text or HTML.

Display	4×20 line 0.3” character height alphanumeric LCD module display
Sensor	J/K/R Thermocouples and 3 wire PT100 sensor user selectable
Range	J-T/C : 0 to 750˚C K-T/C : 0 to 1250˚C R-T/C : 0 to 1700˚C PT100: -100.0 to +600.0˚C
Resolution	1˚C for thermocouples and 0.1˚C for PT100
Channels	Maximum 16
Scanning Rate	User settable from 1-99seconds
Digital Offset	User settable individually for each channel
Logging Rate	1 second to 99Mins59seconds
Data Logging	Directly create a .csv file on the Pen Drive (compatible with Excel) giving a tabular format values of Date, Time and selected channels
Real Time Clock	Adjustable Calendar (Month/Date) and Time (Hrs:Mins)
Accuracy	±1˚C ± 1 Least Significant Digit for Thermocouples ±0.1˚C ± 1 Least Significant Digit for PT100
Power Supply	230V AC ± 15% at 50/60Hz
Mounting Type	Panel Type
Front Facia	96mm x 192mm

Additional Information

Display:

4×20 line 0.3” character height alphanumeric LCD module display

Sensor:

J/K/R Thermocouples and 3 wire PT100 sensor user selectable

Range:

J-T/C : 0 to 750˚C K-T/C : 0 to 1250˚C R-T/C : 0 to 1700˚C PT100: -100.0 to +600.0˚C

Resolution:

1˚C for thermocouples and 0.1˚C for PT100

Channels:

Maximum 16

Scanning Rate:

User settable from 1-99seconds

Digital Offset:

User settable individually for each channel

Logging Rate:

1 second to 99Mins59seconds

Data Logging:

Directly create a .csv file on the Pen Drive (compatible with Excel) giving a tabular format values of Date, Time and selected channels

Real Time Clock:

Adjustable Calendar (Month/Date) and Time (Hrs:Mins)

Accuracy:

±1˚C ± 1 Least Significant Digit for Thermocouples ±0.1˚C ± 1 Least Significant Digit for PT100

Power Supply:

230V AC ± 15% at 50/60Hz

Mounting Type:

Panel Type

Front Facia:

96mm x 192mm
